Description

Description:
Horsepower & Torque: 341 Horsepower / 371 FT. LBS. Torque
Compression Ratio: 9.2:1
Aluminum Heads
Hydraulic Roller Cam
Cast Crankshaft
Hypereutectic Pistons
Block:
Kezar’s Perfomance High Strength Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.000″ Bore
1-Piece Rear Main Seal
Mech Fuel Pump Provision: Yes
Passenger Side Dipstick
Drilled and Tapped for Clutch Linkage
Rotating Assembly:
Cast Crankshaft
3.480″ Stroke
Forged 5.700″ Connecting Rods
Hypereutectic Pistons
Internally Balanced Front – Externally Balanced Rear
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – H8002K
64cc Chamber
2.02″ Intake / 1.60″ Exhaust Valves
195cc Intake / 75cc Exhaust Runners
Cam Specs:
Hydraulic Roller
.477 Intake / .471 Exhaust Lift
202 Intake / 212 Exhaust Duration
@ .050-115 Degree Lobe Separation
Ignition Timing:
32 Degrees Total at 3500 RPM
Also Includes:
Valve Covers
Rear Sump Oil Pan
Timing Cover
Aluminum Intake
HEI Distributor
Spark Plugs and Wires
Holley Sniper 2 EFI
Water Neck
Thermostat and Thermostat Housing
Front Accessory Drive with Water Pump, A/C Compressor, Alternator, and Power Steering Pump
