Description

Description:
Horsepower & Torque: 405 Horsepower / 446 FT. LBS. Torque
Compression Ratio: 10.0:1
Aluminum Heads
Hydraulic Roller Cam
Cast Crank
Hypereutectic Pistons
Block:
Kezar’s Perfomance High Strength Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.000″ Bore
1-Piece Rear Main Seal
Mech Fuel Pump Provision: Yes
Passenger Side Dipstick
Drilled and Tapped for Clutch Linkage
Rotating Assembly:
Cast Crankshaft
3.750″ Stroke
OEM Type 5.700″ Connecting Rods w/ 150,000 PSI Bolts
Hypereutectic Pistons
Externally Balanced Front and Rear
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – H8002K
64cc Chamber
2.02″ Intake / 1.60″ Exhaust Valves
195cc Intake / 75cc Exhaust Runners
Cam Specs:
Cam Type: Roller
.495 Intake / .502 Exhaust Lift
220 Intake / 224 Exhaust Duration
@ .050-114 Degree Lobe Separation
Also Includes:
Intake Manifold Dual Plane, Satin Aluminum
Holley Sniper 2 EFI System
Valve Covers
Oil Pan
Timing Cover
EFI Fuel Pump Kit
Spark Plugs and Wires
Thermostat and Thermostat Housing
Oil Filter
Plug Wire Separators
Polished Front Accessory Drive with Water Pump, A/C Compressor, Alternator, and Power Steering Pump
Assembled with Complete Transfer Case Ready 700r4 Automatic Transmission Package:
700R4 Complete Package. Features 4wd 27 Spline Stub Shaft, and Transfer Case Ready, 4wd Case.
(Accepts common GM 4 Bolt Transfer Case)
2200-2400 Stall Torque Converter
Flex Plate
Starter
