Description

Description:
Horsepower & Torque: 530 Horsepower / 495 FT LBS
Compression Ratio: 10.7:1
Aluminum Heads
Hydraulic Roller Cam
Nodular Iron Crankshaft
Hypereutectic Pistons
Block:

Kezar’s Perfomance High Strength Cast Iron (LSX Style) Block
Increased Deck Thickness and Strength Webbing
Extended Cylinder Skirt
Priority Main Oiling
4.0662″ Bore
6-Bolt Main
1-Piece Rear Main Seal
Improved Water Jacket Design
Utilizes OEM LS3 Front and Rear Covers.
Rotating Assembly:
Nodular Iron Crankshaft
3.622″ Stroke
6.125″ Connecting Rods w/ 150,000 PSI Bolts
Hypereutectic Pistons
Internally Balanced Front and Rear
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – PS8015
69cc Chamber
2.165″ Intake / 1.590″ Exhaust Valves
259cc Intake / 102cc Exhaust Runners
Cam Specs:
Cam Type: Hydraulic Roller Cam
.612 Intake / .585 Exhaust Lift
225 Intake / 238 Exhaust Duration
@.050-113 Degree Lobe Separation
Also Includes:
LS Swap Oil Pan
DBW Throttle Body
GM Plastic Intake Manifold
Fuel Injectors and Rail
Coil Packs
Spark Plugs and Wires
Water Pump
Harmonic Balancer
