Description:
Horsepower & Torque: 600 Horsepower / 530 FT LBS
Compression Ratio: 11:1
Aluminum Heads
Hydraulic Roller Cam
Forged Crank
Forged Pistons
Block:

Kezar’s Perfomance High Strength Cast Iron (LSX Style) Block
Increased Deck Thickness and Strength Webbing
Extended Cylinder Skirt
Priority Main Oiling
4.0685″ Bore
6-Bolt Main
1-Piece Rear Main Seal
Improved Water Jacket Design
Utilizes OEM LS3 Front and Rear Covers
Rotating Assembly:
New Forged Crankshaft
4.125″ Stroke
Forged 6.125″ Connecting Rods
Forged Pistons
Internally Balanced Front and Rear
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – PS8015
69cc Chamber
2.165″ Intake / 1.590″ Exhaust Valves
259cc Intake / 102cc Exhaust Runners
Cam Specs:
Hydraulic Roller
.624 Intake / .624 Exhaust Lift
239 Intake / 255 Exhaust Duration
@.050-114 Degree Lobe Separate
Ignition Timing:
ECM Supplied with Calibration
Not Capable of Transmission Control
Transmission Controller Required
Also Includes:
Valve Covers
LS Swap Oil Pan
Timing Cover
Drive by Wire Throttle Body
Engine Harness and ECU Kit
LS3 Fabricated Intake Manifold
Injectors and Fuel Rail Kit
Coil Packs
Spark Plugs and Wires
Water Pump
Harmonic Balancer
Throttle Pedal
