Description

Description:
Horsepower & Torque: 525 Horsepower / 460 FT LBS
Compression Ratio: 10.7:1
BluePrint LS3 Aluminum Heads
Hydraulic Roller Cam
Block:

Kezar’s Perfomance High Strength Cast Iron (LSX Style) Block
Increased Deck Thickness and Strength Webbing
Extended Cylinder Skirt
Priority Main Oiling
4.0662″ Bore
6-Bolt Main
1-Piece Rear Main Seal
Improved Water Jacket Design
Utilizes OEM LS3 Front and Rear Covers
Rotating Assembly:
Nodular Iron Crankshaft
3.622″ Stroke
6.098″ Connecting Rods w/ 150,000 PSI Bolts
Hypereutectic Pistons
Internally Balanced Front and Rear
Cylinder Heads:
BluePrint LS3 Aluminum Cylinder Heads – PS8015
69cc Chamber
2.165″ Intake / 1.590″ Exhaust Valves
259cc Intake / 102cc Exhaust Runners
Cam Specs:
Cam Type: Roller Cam
.612 Intake / .585 Exhaust Lift
225 Intake / 238 Exhaust Duration
@.050-113 Degree Lobe Separation
Ignition Timing:
Controlled by Customer Sourced Engine Management. (Not Included)
Also Includes:
Valve Covers
LS Swap Oil Pan
Timing Cover
Drive by Wire Throttle Body
LS3 Fabricated Aluminum Intake Manifold
Injectors and Fuel Rail Kit
Coil Packs
Spark Plugs
Water Pump
Harmonic Balancer
