Description

Description:
Horsepower & Torque: 605 Horsepower / 565 FT LBS
Compression Ratio: 11:1
Aluminum Heads
Hydraulic Roller Cam
Forged Crank
Forged Pistons
Block:

Kezar’s Perfomance High Strength Cast Iron (LSX Style) Block
Increased Deck Thickness and Strength Webbing
Extended Cylinder Skirt
Priority Main Oiling
4.0685″ Bore
6-Bolt Main
1-Piece Rear Main Seal
Improved Water Jacket Design
Utilizes OEM LS3 Front and Rear Covers.
Rotating Assembly:
New Forged Crankshaft
4.125″ Stroke
Forged 6.125″ Connecting Rods
Forged Pistons
Internally Balanced Front and Rear
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – PS8015
69cc Chamber
2.165″ Intake / 1.590″ Exhaust Valves
259cc Intake / 102cc Exhaust Runners
Cam Specs:
Hydraulic Roller
.624 Intake / .624 Exhaust Lift
239 Intake / 255 Exhaust Duration
@.050-114 Degree Lobe Separation
Also Includes:
Drive by Wire Throttle Body
42# Injectors and Returnless Fuel Rail
Harmonic Balancer
Valve Covers
LS Swap Oil Pan
Timing Cover
Coil Packs
Spark Plugs and Wires
GM Plastic Intake Manifold
