Description
Quick Time RM-6022W Details
The Quick Time RM-6022 bellhousing connects small block and big block Chevy engines to transmissions utilizing the GM standard pattern such as the Muncie, Saginaw, Borg Warner T10 and Tremec TKO transmissions. This bellhousing is S.F.I. 6.1 certified which is required by many sanctioning bodies for cars running 11.49 or faster in the quarter mile. This bellhousing is a universal fit bellhousing and is not vehicle specific. The Quick Time bellhousings are produced using a unique spin forming process which results in a very high strength material. This high material strength allows the Quick Time bellhousings to be light weight while maintaining the protection you desire. Note: (Transmission Mounting Bolts Not Included)
Quick Time RM-6022W Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | RM-6022W |
| Brand | Quick Time |
| Material Type | Steel |
| Finish | Black |
| SFI Rating | 6.1 |
| Transmission Type | Manual |
| GENERAL | |
| Overall Height | 6.29″ |
| Sold in Quantity | Kit |
| GTIN Code | 084041027875 |
| Clutch Operation | Mechanical or Hydraulic |
| Flywheel | 153/168 |
| Clutch Fork Included | No |
| Block Plate Included | Yes |
| Adjustable Fork Pivot Recommended | No |
| Transmission Bore Diameter | 4.687 in. |
