Description

Description:
Horsepower & Torque: 511 Horsepower / 480 FT. LBS. Torque
Compression Ratio: 9.5:1
Aluminum Heads
Hydraulic Roller Cam
Forged Steel Crank
Forged Pistons
Block:
Kezar’s Perfomance High Strength Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.125″ Bore
1-Piece Rear Main Seal
Mech Fuel Pump Provision: Yes
Passenger Side Dipstick
Drilled and Tapped for Clutch Linkage
Rotating Assembly:
New BluePrint Forged Steel Crankshaft
3.750″ Stroke
6.000″ Forged Connecting Rods
Forged Pistons
Internal Front/ External Rear Engine Balance
Dual Keyway Damper installed
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – HP8103
64cc Chamber
2.08″ Intake / 1.60″ Exhaust Valves
220cc Intake / 67cc Exhaust Runners
Cam Specs:
Cam Type: Roller
.555 Intake / .577 Exhaust Lift
236 Intake / 248 Exhaust Duration
@.050-113 Degree Lobe Separation
1.6 Roller Rockers
Ignition Timing:
10-16° Initial and Total Timing 32-34° at 3500 RPM
Also Includes:
Valve Covers
Oil Pan
Timing Cover
