Description

Description:
Horsepower & Torque: 500 Horsepower / 500 FT. LBS. Torque
Compression Ratio: 10.3:1
Aluminum Heads
Hydraulic Roller Cam
Forged Crank
Forged Pistons
Block:
Kezar’s Perfomance High Strength Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.125″ Bore
1-Piece Rear Main Seal
Mech Fuel Pump Provision: Yes
Passenger Side Dipstick
Drilled and Tapped for Clutch Linkage
Rotating Assembly:
New BluePrint Forged Crankshaft
3.750″ Stroke
Forged I Beam 5.700″ Connecting Rods w/ 150,000 PSI Bolts
Forged Pistons
Internally Balanced Front – Externally Balanced Rear
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – HP8103
64cc Chamber
2.08″ Intake / 1.60″ Exhaust Valves
220cc Intake / 67cc Exhaust Runners
Cam Specs:
Cam Type: Roller
.555 Intake / .576 Exhaust Lift
236 Intake / 242 Exhaust Duration
@ .050-110 Degree Lobe Separation
Ignition Timing:
10-16° Initial and Total Timing 32-34° at 3500 RPM
Also Includes:
Intake Manifold Dual Plane, Satin Aluminum
Holley Sniper 2 EFI System
Valve Covers
Oil pan
Timing Cover
EFI Fuel Pump Kit
Spark Plugs and Wires
Thermostat and Thermostat Housing
Oil Filter
Plug Wire Separators
Polished Front Accessory Drive with Water Pump, A/C Compressor, Alternator, and Power Steering Pump
Assembled with Complete 700r4 Automatic Transmission Package:
700R4 Complete Package
2200-2400 Stall Torque Converter
Flex Plate
Starter
