Description

Description:

Horsepower & Torque: 341 Horsepower / 371 FT. LBS. Torque
Compression Ratio: 9.2:1
Aluminum Heads
Hydraulic Roller Cam
Cast Crankshaft
Hypereutectic Pistons
Block:
Kezar’s Perfomance High Strength Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.000″ Bore
1-Piece Rear Main Seal
Mech Fuel Pump Provision: Yes
Passenger Side Dipstick
Drilled and Tapped for Clutch Linkage
Rotating Assembly:
Cast Crankshaft
3.480″ Stroke
Forged 5.700″ Connecting Rods
Hypereutectic Pistons
Internally Balanced Front – Externally Balanced Rear
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – H8002K
64cc Chamber
2.02″ Intake / 1.60″ Exhaust Valves
195cc Intake / 75cc Exhaust Runners
Cam Specs:
Hydraulic Roller
.477 Intake / .471 Exhaust Lift
202 Intake / 212 Exhaust Duration
@ .050-115 Degree Lobe Separation
Ignition Timing:
32 Degrees Total at 3500 RPM
Also Includes:
Holley Street Warrior 600cfm Vacuum Secondary Carburetor w/ Electric Choke
Valve Covers
Harmonic Balancer
Spark Plugs
Spark Plug Wires
Standard Rotation Long Style Water Pump
Water Neck
Thermostat and Thermostat Housing
Fuel Pump
Rear Sump Oil Pan
Timing Cover
Aluminum Intake
HEI Distributor
