Description

Description:
Horsepower & Torque: 615 Horsepower / 579 FT. LBS. Torque
Compression Ratio: 8.5:1
Aluminum Heads
Solid Roller Cam
Forged Crank
Forged Pistons
Block:
Kezar’s Perfomance High Strength Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.500″ Bore
1-Piece Rear Main Seal
Mech Fuel Pump Provision: Yes
Standard Deck
Rotating Assembly:
New BluePrint Forged Crankshaft
4.250″ Stroke
Dual Keyway
Forged H-beam 6.385″ Connecting Rods
Forged Pistons
Internally Balance
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – PS8013
119cc Chamber
2.30″ Intake / 1.88″ Exhaust Valves
316cc Intake / 124cc Exhaust Runners
Cylinder Heads Feature a .300 in. Raised Exhaust Port vs an OEM Casting
Must Verify Header / Exhaust Clearance
Cam Specs:
Cam Type: Solid Roller
.652 Intake / .652 Exhaust Lift
255 Intake / 262 Exhaust Duration
@ .050-114 Degree Lobe Separation
Ignition Timing:
Initial Timing 10-16° and Total Timing 32-34°
Also Includes:
Valve Covers
Oil Pan
Timing Cover
Roller Rockers with Stud Girdles
SFI Rated Dual Keyway 8 in. Balancer
