Description
AutoMeter 4467 Details
High brake system pressures make this an environment that few gauges are up to the task of handling. Auto Meter’s Digital Stepper Motor Brake Pressure Gauge provides not only the accuracy you expect from a top of the line instrument, but the durability you need under even the most demanding conditions. Includes a highly advanced 1/8″ NPT Pressure Transducer and wiring harness for ease of installation. Data Logging is also possible thanks to an analog .5 – 4.5v output.
- Includes bulb and socket assembly with red and green bulb covers
- Includes 8ft. Wiring Harness
- Includes 1/8″ NPT Sender.
- Includes 1/8″ NPT to 1/4″ NPT adapter/fitting
- Includes gauge mounting hardware and installation instructions
- Full sweep precision digital stepper motor meter movement
Ships with the following AutoMeter products:
Sending Unit(s): 2240
Wire Harness: 5227
Bulb & Socket: 3220
Light Covers: Red 3214 & Green 3215
Mounting Hardware: 3245
Ships with the following AutoMeter products:
Sending Unit(s): 2240
Wire Harness: 5227
Bulb & Socket: 3220
Light Covers: Red 3214 & Green 3215
Mounting Hardware: 3245
AutoMeter 4467 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 4467 |
| Brand | AutoMeter |
| Gauge Type | Electric |
| Gauge Range | 0-1600 PSI |
| Overall Diameter | 2-5/8 |
| Bezel Finish | Brushed Aluminum |
| Sending Unit Included | Yes |
| Gauge Face Color | Silver |
| GENERAL | |
| GTIN Code | 046074044670 |
| Bezel Style | Super Bezel |
| Lighting Type | Incandescent |
| Includes Wire Harness | Yes |
| Needle Color | Fluorescent Red |
| Light Color | White Incandescent |
| Includes Mounting Bracket(s) | Yes |
| Includes Bulb and Socket | Yes |
| Includes Light Covers | Yes |
| Sold in Quantity | Each |
