Description

Description:
Horsepower & Torque: 415 Horsepower / 415 FT LBS
Compression Ratio: 10.0:1
Aluminum Heads
Cast Crankshaft
Hydraulic Roller Cam
Block:
Kezar’s Perfomance High Strength Cast Iron Block
Increased Deck Thickness and Strength Webbing
Priority Main Oiling
4.000″ Bore
4-Bolt Main
1-Piece Rear Main Seal
Improved Water Jacket Design
Rotating Assembly:
Cast Crankshaft
3.400″ Stroke
Forged 5.400″ Connecting Rods
Forged Pistons
28oz Externally Balanced Front and Rear
Cylinder Heads:
BluePrint Aluminum Cylinder Heads – HP9009
60cc Chamber
2.02″ Intake / 1.60″ Exhaust Valves
190cc Intake / 60cc Exhaust Runners
Cam Specs:
Hydraulic Roller Cam
.543 Intake / .554 Exhaust Lift
218 Intake / 226 Exhaust Duration
@.050-112 Degree Lobe Separation
Ignition Timing:
10-16 Degrees Initial, 32-34 Total
Also Includes:
Dual/Rear Sump Oil Pan
Valve Covers
Timing Cover
