BLOCK:
New standard bore stroker style block
Square and parallel decked
Align honed main bearing bore
Cylinders honed on computer controlled machine to within .0002 straightness and roundness
Cylinders are sonic tested for thickness
2-Bolt Main
1-Piece Rear Main Seal
Mech fuel pump provision: Yes

ROTATING ASSEMBLY:
New BluePrint Cast steel crankshaft
3.400″ Stroke
Forged I-beam 5.400″ connecting rods
Forged pistons
28oz External balance

CYLINDER HEADS:
BluePrint Aluminum Cylinder Heads -HP9008
60cc chamber
2.02″ intake/1.60″ exhaust valves
190cc intake/65cc exhaust runners

CAM SPECS:
Cam Type: Roller
.543 Intake .554 Exhaust
218 Intake / 226 Exhaust duration
@ .050 – 112 degree lobe separation

IGNITION TIMING:
34 Degrees Total at 3500 RPM

ALSO INCLUDES:
Rear Sump Oil Pan
Valve Covers
Timing Cover
Distributor
Carburetor
Spark Plugs and Wires
Waterpump
Harmonic Balancer
Installed Complete Black front accessory Drive. WP, Alt, P/S, A/C, all belts and pulleys.
Dyno test results shipped with engine

WARRANTY:
30 month / 50,000 mile
